Toshiba BX420D Industrial Direct Thermal Label Printer 203dpi USB LAN BX420D-GS02-QM-S

Toshiba BX420D Industrial Direct Thermal Label Printer 203dpi USB LAN BX420D-GS02-QM-S

Main Features:

Physical & Electrical

• Printhead Type: Flat head
• Print Method: Direct thermal
• Memory: 1 GB RAM, 8 GB ROM
• Dimensions (W x D x H): 278 mm x 460 mm x 310 mm (10.94" x 18.11" x 12.20")
• Weight: 15.2 kg (33.51 lb)
• User Interface: Color LCD with LED backlight, 11 Keys, 272 x 480 dots Graphic LCD
• Operating Temp. / Humidity: 5°C to 40°C (41°F to 104°F) / 25% to 85% RH (no condensation)
• Power Supply: AC 100 to 240V, 50/60 Hz

Print Performance

• Resolution: 203 dpi (8 dot/mm)
• Max. Print Speed: 304.8 mm/sec (12"/sec)
• Max. Print Width: 104 mm (4.09”)
• Max. Print Length: 1,496 mm (58.89")

Ribbon Specs

• Ribbon Width: 40 mm to 112 mm (1.57" to 4.40")
• Ribbon Length: 600 m (23,622.04')

Media Handling

• Alignment: Centered
• Media Width (incl. backing): 25 mm to 114 mm (0.98" to 4.48")
• Label Thickness: 0.13 mm to 0.17 mm (0.005" to 0.006")
• Inner Media Core Diameter: 76.2 mm (3"), 40.0 mm (1.57"), 38.0 mm (1.49")
• Max. Outer Media Roll OD: Ø200 mm (Ø7.87")
• Media Format: Roll, fanfold

Software & Connectivity

• Emulations: Auto-detection of TPCL, ZPL II, DPL, SBPL, IPL, PDF
• Printer Drivers: Windows 11/10, Windows Server 2019/2016, SAP, CUPS driver for Linux, macOS
• SDK Availability: iOS, Android, Windows, Java
• Interface Ports: USB 2.0 HS (USB host/HID support), LAN 10/100/1000 BaseT, RS232C(1), WLAN 802.11ac/a/b/g/n/ax(1)(2), Bluetooth 5.2(1)(2), Expansion I/O(1)
• Native Language Mode: TPCL
• Bundled Label Software: NiceLabel free, BarTender UltraLite
• IoT Device Management: e-BRIDGE CloudConnect
