Opticon OPL-250 2D Corded Barcode Scanner USB Cable (L-250)

The L-250 is a high performance handheld barcode scanner with outstanding durability and reliability. The integrated Opticon 2D CMOS imaging technology provides true point-and- shoot barcode scanning.

Features:

• High speed 2D CMOS imager
• Efficiently scans and decodes a wide variety of 1D or 2D barcodes
• The L-250 comes standard with antimicrobial properties
• Custom configuration capabilities including multi-read
• Enhanced motion tolerance
• Improved scanning of curved, wide and poorly printed barcodes
• Pre-configured to suit a wide range of applications
• LED indicators on the top of the scanner
• Durable – survives 1.5 meter drop to concrete
• Trigger modes: manual, auto-trigger and stand detection
• Communication interface: USB
• Composite device (both serial and HID. Serial is always available for configuration)
• Available in black
• Available accessories: stand
• Backed by a two year warranty

Supported Symbologies:

• Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/
• NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128
• (EAN-128), GS1 Databar (RSS), IATA, Industrial 2of5,
• Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/
• Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
• Postal code: Chinese Post, Intelligent Mail Barcode,
• Korean Postal Authority code, POSTNET
• 2D code: Aztec Code, Aztec Runes, Chinese Sensible
• code, Codablock F, Composite codes, Data matrix
• (ECC200), Passport MRZ (OCR-B), maxi Code (mode
• 2~5), MicroPDF417, MicroQR Code, PDF417, QR Code

2D Imager Optics:

• Light source: Aiming green LED, cool white illumination LED
• Scan method: CMOS area sensor, 640 x 480 pixels
• Scan rate: Up to 100 fps
• Trigger mode: Manual, auto-trigger
• Reading pitch angle: 3600
• Reading skew angle: 150
• Reading tilt angle: 3600
• Curvature: R≥20 mm (UPC)
• Min. resolution at PCS 0.9: 0.2 mm
• Field of view: Horizontal 33.20, Vertical 25.40
• Min. PCS value: 0.2
• Depth of field at code 39:
• 30 - 150 mm (0.127 mm) / 1.18- 5.9 in (5 mil)
• 50 - 210 mm (0.254 mm) / 1.97 – 8.27 in (10 mil)
• 100 - 240 mm (0.508 mm) / 3.94 – 9.45 in (20 mil)
• Depth of field at code 128:
• 25 - 150 mm (0.2 mm) / 0.98 – 5.9 in (7.9 mil)
• Depth of field at EAN/UPC:
• 30 - 230 mm (0.33 mm) / 1.18 – 9.06 in (13 mil)
• Depth of field at PDF417:
• 20 - 140 mm (0.169 mm) / 0.79 – 5.51 in (6.7 mil)
• 36 - 190 mm (0.254 mm) / 1.42 – 7.48 in (10 mil)
• Depth of field at QR code:
• 30 - 115 mm (0.169 mm) / 1.18 – 4.53 in (6.7 mil)
• 50 - 200 mm (0.381 mm) / 1.97 – 7.87 in (15 mil)
• Depth of field at Data Matrix:
• 40 - 110 mm (0.169 mm) / 1.57 – 4.33 in (6.7 mil)
• 20 - 145 mm (0.254 mm) / 0.79 – 5.7 in (10 mil)
